C-Series Triple-Pole Flat Rocker Circuit Breaker

About This Product

The Blue Sea Systems 1168 is a 120/240V AC 360 Panel System module with one installed 50A triple-pole C-Series flat rocker breaker. It is built for boats that need a compact main AC breaker section in a Blue Sea modular panel layout, with a rocker-style actuator and backlit label positions for easier circuit identification.

This module measures 4.75 in high, 4.88 in wide, and 3.00 in deep. The layout includes spare rocker apertures that can be used for single-pole 120V AC or double-pole 240V AC branch circuits, which helps when you are building out a panel around the way the boat is actually wired.

Key Features

• One 50 Ampere triple-pole C-Series circuit breaker installed
• Backlit circuit label positions
• Flexible 360 Panel System configuration provides spare rocker apertures which may be used for single-pole 120 Volt AC or double-pole 240 Volt AC Branch circuits

Technical Specification

Positions1Nominal Voltage120/240V ACHeight4.75in (120.65 mm)Width4.88in (123.95 mm)Depth3.00in (76.2 mm)

No Documentation available.
