About This Product
This Low Profile Cable Seal is designed to provide a sleek, flush-mounted solution for routing larger pre-terminated cables through roofs, decks, and vehicle surfaces while maintaining a guaranteed IP68 waterproof seal. Engineered for 9–14 mm (0.35–0.55″) cables and connectors up to 30 mm (1.18″), the recessed design reduces the installed height by approximately 68% compared to traditional cable seals, creating a clean, factory-quality finish. Constructed from black anodized marine-grade aluminum, it offers outstanding corrosion resistance, impact durability, and long-term outdoor performance, making it ideal for solar installations, Starlink, antennas, lighting, and other rooftop electronics.
Key Features
- Ultra Low-Profile Design – Reduces installed height by approximately 68% for a clean, flush appearance.
- IP68 Waterproof Protection – Guaranteed watertight seal for demanding marine, RV, and overland applications.
- Black Anodized Marine-Grade Aluminum – Corrosion-resistant construction built for long-term outdoor durability.
- Fits 9–14 mm Cables – Ideal for larger power, communication, RF, and data cables.
- Supports Connectors up to 30 mm – Install pre-terminated cables without removing factory-fitted connectors.
- Split-Bung Design – Simplifies installation while maintaining a secure waterproof seal.
- Recessed Mounting System – Conceals the sealing technology below the mounting surface for a premium finished appearance.
- No Messy Sealant Required – Closed-cell base gasket provides a clean, professional installation.
- Captive Nut Design – Enables quick installation and reliable repeat servicing.
Technical Specification
Maximum Number of Cables1Cable Diameter Range9–14 mm (0.35–0.55″)Maximum Connector Diameter30 mm (1.18″)Cable Seal Diameter75.6 mm (2.98″)nstalled Height Above Surface6.5 mm (0.26″)
No Documentation available.
