Passive Ventilation Grille 17″

The AIRFRAME Grille 7 is a 16.5 by 6.5 inch aluminium grille that can be installed into doors, cabinets, and walls to help increase ventilation . The grille can also be used in conjunction with a fan system to act as a passive intake or exhaust vent. To mount the grille into your cabinet or wall, you would need to cut a rectangle hole approximately 14.5 by 5 inches. Features a CNC machined anodized aluminum frame with a brushed black finish and matching flat-head screws. Information on the additional included hardware can be found below.

Key Features

• Designed to be installed into doors, cabinets, and walls to help increase ventilation.
• Can also be used in conjunction with a fan system to act as an intake or exhaust vent.
• Ventilation grille design maximizes airflow while maintaining frame’s structural integrity.
• Features a CNC machined aluminum frame, with a brushed black finish and flat screw heads.
• Kit includes (4) wood mounting screws and (4) machine mounting screws with nuts.

Technical Specification

Total Dimensions16.5 x 6.5 in. (41.2 x 16.5 cm)Required Mounting Hole14.5 x 5 in. (36.8 x 12.7 cm)Hole to Hole Distance15.9 x 5.8 in. (40.3 x 14.8 cm)Screw Hole SizeØ 0.197 in (Ø 0.5 cm)MaterialsAluminiumFinishAnodized BrushedColorBlack
