About This Product
With the SERV+ digital switching system display, you can control and monitor your RV systems and entertainment from a sleek touchscreen for a smart RV experience.
Instead of many physical switches, the SERV+ digital interface lets you control and monitor your onboard systems in one sleek display — for a smart RV experience.
This digital switching display features 5 input channels and 6 output channels to consolidate your controls in one place. However, combine SERV+ with EmpirBus systems, and the number of inputs and outputs are almost endless.
Control onboard music, lights, temperature settings and more by integrating with Garmin, Fusion and EmpirBus products.
The SERV+ touchscreen works with your RV’s setup and can be mounted in either portrait or landscape mode with minimal mounting depth.
Key Features
- Get the smart rv experience with touchscreen control
- Integrate with garmin, fusion and empirbus products
- Mount in portrait or landscape orientation
- View video from your compatible ip security cameras
- Use voice or app control from anywhere in your rv
- Control and monitor systems with the rv controls smartphone app
Technical Specification
GeneralDisplay size7” or 10″Physical dimensions (WxHxD)7″ – 209.2 x 123.3 x 38.6 mm (8.24” x 4.85” x 1.52”) 10″ – 281.2 x 176.4 x 38.7 mm (11.07” x 6.94” x 1.52”)Weight7″ – 438 g (1.0 lbs) 10″ – 720 g (1.6 lbs)Display resolution7″ – WSVGA, 1024 x 600 10″ – WXGA, 1280 x 800TouchscreenyesMounting optionsportrait or landscapeMemory card1 microSD® card slot; 2 TB max card sizeCommunicationWi-Fi® connectivity, Ethernet, CAN-bus, RVC, LINAmbient temperature-10° to 55°C (14° to 131°F)Power SupplySupply voltage10 to 16 VdcMaximum current7″ – 30 A (.55 A with no output channel load) 10″ – 30 A (.8 A with no output channel load)Maximum power usage480 W (8 W with no output channel load)Input 8 Channels (Configurable analog/digital5 configurable inputs, RVC+/-, LIN)DigitalInput peak/average current (12 V)170 mA/1 mAInput weak signal low side/high side1 mA/4 mACurrent drive50mAAnalogInput voltage range0-16 V +/-1%*Input resistance range0-1500 ohm +/- 5%Output 6 ChannelsOutput channels6 High side PWM, 1-10A**
