About this product
Shelly Wall Display XL (the Device) is a smart home control panel with a 10.1” color display and load circuit switching functionality.
The US version features power base that is compatible with the electrical dry-wall boxes in USA.
Key Features
- Touch-sensitive 10.1” color display
- Easy navigation and customizable home screen
- Integrated relay for appliance control
- Integrated 2x 2 W speakers
- Integrated On/Off screen button
- Integrated 4 buttons fully customizable for easy control of set devices
- Integrated light sensors
- Power consumption monitoring of all devices in a room in your Shelly Smart Control account
Technical Specification
Size (HxWxD)155,8×272,5×38,3 mm / 6.13×10.7×1.50 inchWeight1030 g / 36.33 ozTouch Screen5-point capacity screen, G+FF touchScreen resolution1280x752 pxConductor cross section0.75 to 2.5 mm² / 18 to 14 AWG (solid, stranded, and bootlace ferrules)Shell materialMetal stamping, PC with coating, glassSpeaker2x 2 W (BOX sound cavity)Ambient working temperature-20 °C to 40 °C / -5 °F to 105 °FPower supply100 – 240 V~ 50/60HzPower consumption<15 WUSB TYPE-C power supply5 V⎓ / 3 A
No Documentation available.
