About this product
Shelly 1 Mini Gen4 is a small form factor smart switch with potential-free contacts, which allows remote control of electric appliances through a mobile phone, tablet, PC, or home automation system. It can work standalone in a local Wi-Fi network or it can also be operated through cloud home automation services. The device is an improved version of Shelly 1 Mini Gen3 with a more advanced processor and Zigbee connectivity.
Shelly 1 Mini Gen4 can be accessed, controlled and monitored remotely from any place where the User has internet connectivity, as long as the device is connected to a Wi-Fi router and the Internet.
It can be retrofitted into standard electrical wall boxes, behind power sockets and light switches or other places with limited space.
Shelly 1 Mini Gen4 has embedded Web Interface which can be used to monitor and control the device, as well as adjust its settings.
The device has multi-protocol wireless MCU which provide Zigbee and Bluetooth connectivity ensuring a secure connection.
This device is compatible with Matter.
Key Features
- Multiprotocol connectivity: Choose from Wi-Fi, Zigbee and Bluetooth
- Matter-certified
- Supports up to 8 A at 240 VAC and 5 A at 30 VDC
- Dry contacts (potential-free) – option for contactor control
- Perfect to retrofit behind existing switches and sockets
- Wi-Fi and Zigbee range extender & Bluetooth gateway
- Supports schedules, scenes and local actions
- Supports scripting, HTTPS, MQTTS, Inbound and Outbound Web Sockets
- No hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Home Assistant, or your preferred automation platform.
Technical Specification
Size (HxWxD)29x34x16 ±0.5 mm / 1.34×1.11×0.63 ±0.02 inchWeight19 ±1 g / 0.65 ±0.04 ozConductor cross section0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules)MountingWall boxShell materialPlasticAmbient working temperature-20 °C to 40 °C / -5 °F to 105 °FPower supply110 – 240 V~RelayDry, NO contact, 1-pole, µ contactPower consumption<1.2 W
